Woodpecker XF

Woodpecker XF Band Saw Blades

Woodpecker XF blades have a flexible carbon steel back and ground, induction hardened teeth and are available in a variety of pitches. Available as thin as .014", they provide cost effective sawing with minimal material loss for cabinet making, woodworking products and sawing furniture.

Features

Products

Blade Width x Thickness		Blade Pitch, Rake & Tooth Shape with Material Numbers
All sizes available in 100' (30m) & 250' (76m) coils. All sizes except 91135, 91920 & 91254 available in 500' (152m) coils. P: Positive Rake. S: Straight (Zero) Rake. K: Skip. LP: Low Profile. HP: High Profile.
Inch	mm	2/P Hook	3/P Hook	3/P-LP Hook	3/P-HP Hook	3/S-K Skip	4/P Hook	4/P-HP Hook	4/S-K Skip	6/P-HP Hook	6/S-K Skip
1/4" x .014"	6.5 x 0.35mm										91135
1/4" x .020"	6.5 x 0.50mm						91991				91992
1/4" x .032"	6.5 x 0.80mm							91920
3/8" x .014"	10 x 0.35mm										91254
3/8" x .022"	10 x 0.55mm								91996
3/8" x .025"	10 x 0.65mm							91250	91240	91264
3/8" x .032"	10 x 0.80mm				91930			91940
1/2" x .022"	13 x 0.55mm						92001
1/2" x .032"	13 x 0.80mm							91960	91965
5/8" x .022"	16 x 0.55mm		92003				92004
3/4" x .022"	19 x 0.55mm						92006
3/4" x .028"	19 x 0.65mm		92007
3/4" x .032"	19 x 0.80mm			91515		91510		91528		91542
1" x .023"	25 x 0.58mm	92032	92010
1" x .028"	25 x 0.65mm	92033
1" x .035"	25 x 0.90mm	92036
1-1/4" x .035"	32 x 0.90mm	92044
1-1/4" x .042"	32 x 1.10mm	92045
